External Blu-ray Drive BDR-XS07TUHD
6x Slot Loading Portable USB 3.1 Gen1(3.0) BD/DVD/CD Burner. Support BDXL™ And M-Disc™ Format. USB Bus Powered. Cyberlink Software Included.
- Long-term data protection with M-DISC™
- USB 3.1 Gen1(3.0)
- Equipped with USB Type-C connector
- Slot Loading Mechanism
- Auto Quiet, PowerRead™, and PureRead 4+ features
- Up to 6x writing speed on BD-R & BD-R DL media
- Supports BDXL, Blu-ray, DVD, and CD media
- Windows® 11 / macOS Monterey 12 / macOS Ventura 13 / macOS Sonoma14 / macOS Sequoia 15 Compatible
- Important notice about macOS Catalina Support on PC Drives: https://pioneer.jp/support/download/index-e.html
- Important notice about CyberLink PowerDVD® 14 on PC Drives: https://global.pioneer/en/support/oshirase_etc/pcperipherals/info220630.php
OVERVIEW
The BDR-XS07TUHD slim slot portable USB 3.1 Gen1(3.0) BD/DVD/CD burner is the next generation Blu-ray Disc burner from Pioneer. The BDR-XS07TUHD has a smooth slot loading mechanism that both dependable dustproof and excellent quietness have been realized. The drive supports BDXL and M-DISC format and can read and write to all BDXL discs1 including BD-R triple-layer 100GB media, BD-R quad-layer 128GB media, and BD-RE triple layer 100GB media, as well as conventional Blu-ray discs (single-layer 25GB media and dual-layer 50GB media). The portable device, measuring only 135mm (W) X 135mm (D) X 18.0mm (H) and weighing a mere 280g, also has the ability to be powered directly via USB (no AC adaptor required).
The BDR-XS07TUHD includes CyberLink Software, “CyberLink Media Suite 10” only for Windows OS. It is needed to be downloaded through the WEB. (https://jpn.pioneer/ja/pcperipherals/bdd/eula/cyberlink_media_suite/en.php) Product key for free download is included. PowerDVD™14 delivers award winning playback software and will even upscale standard-definition content to high-definition quality. PowerDirector® 15 LE allows you to import your home movies, edit them, and then upload them to social media sites. Power2Go® 8 gives you the ability to burn your valuable files to Blu-ray (including triple and quad layer BDXL discs), DVD or CD media.
With BDXL and M-DISC support, you can now back up your files with fewer discs than ever before, and since the drive is portable and USB bus powered, all of this can be done virtually anywhere. The BDR-XS07TUHD can write up to 6x2 on BD-R and BD-R dual-layer (DL) media. One BD-R DL disc can hold the same amount of data as 10 DVDs (single-layer). One QL disc can hold the same amount of data as 27 DVDs (single-layer). The drive is also backward compatible to read and write to most DVD and CD recordable media. Click on the "Specifications" tab to see all supported media formats and the read and write/burn speeds achievable for each format.
The BDR-XS07TUHD also has unique features such as PowerRead™³, Auto Quiet mode, and PureRead4+⁴. PowerRead can provide smoother movie playback when a disc has fingerprints or minor surface scratches. Auto Quiet mode intelligently adjusts the disc rotation speed to reduce noise (useful while watching movies or listening to music), and PureRead automatically adjusts the drive parameters to minimize sound glitches during music playback. Auto Quiet mode and PureRead can be configured as well as enabled and disabled with the Pioneer BDR-XS07TUHD Drive Utility.
For information on other PC environment requirements, download the Ultra HD Blu-ray Advisor Tool to your PC, and check. https://pioneer.jp/device_e/product-e/ibs/eula.php
-
-
Long-term data protection with M-DISC™ Support
Support reading and writing M-DISC™(DVD, BD: SL25GB/DL50GB/TL100GB) introduced by Millenniata, Inc.
-
-
Equipped with USB Type-C connector
From XS07 series, the drive has USB Type-C connector. USB Type-C Cable (USB Standard A→USB Type-C and USB Type-C→USB Type-C ) included.
-
-
Compact, well-balanced body
Feel smooth with high-grade rubber coating. Compact, well-balanced body with vertical stand.
-
-
Slot loading mechanism
Both dependable dustproof and excellent quietness have been realized with original slot loading mechanism.
-
-
“PureRead 4+” that faithfully reads audio CDs
Scratches and fingerprints on your CDs can cause them to skip. A drive normally makes a calculated guess at the unreadable data and attempts to correct this to match the original music. However, this is not 100% accurate. PureRead3+, when enabled, makes the drive reread the obscured data to extract the original music as accurately as possible.
-
-
Faster burning
Up to 16x2 writing on BD-R single-layer discs, 14x on BD-R DL discs, and 8x writing on BD-R triple-layer discs.
-
-
Store more data
Up to 156% more data storage capacity than a 50GB Dual Layer Blu-ray Disc. The BDXL™ format supports BDXL Blu-ray media (including 128GB Quadruple Layer (QL)¹ and 100GB Triple Layer (TL)¹ Blu-ray Disc™).
-
-
An eco-friendly drive
Smaller packaging- saves resources and fuel transportation. Reduced power consumption on external USB drives which allows for eco-friendly USB bus-powered drives.
-
-
Smooth movie playback
Scratches, fingerprints and other abnormalities on the surface of a disc can sometimes cause Blu-ray and DVD movie playback to stop. When a PowerRead enabled drive is not able to read through obstructed areas of a disc, it will attempt to move forward quickly to the next available data point, resulting in smoother Blu-ray and DVD movie playback3.
-
-
A smarter drive
Pioneer drives with Auto Quiet mode, monitor how they are being used and adjust their speed automatically – high speed for data transfer, and low speed for music or movie playback.
-
-
Wide blank media support
Pioneer strives to have best-in-class performance over a wide range of media – our drives achieve this for a large variety of BD and DVD media. Refer to the drive’s media support list for all supported media and the write speed that can be achieved.
-
WHAT’S IN THE BOX
- Computer drive - BDR-XS07TUHD
- USB Type-C Cable (USB Standard A→USB Type-C)
- USB Type-C Cable (USB Type-C→USB Type-C)
- Vertical stand & Rubber cushion
- Instruction manual with Product key for software free download– CyberLink Media Suite 10 for UHD Blu-ray
SPECS
SPECS
| MAXIMUM WRITE SPEED (BD) | |||
|---|---|---|---|
| BD-R | 6x | BD-R DL | 6x |
| BD-R TL | 4x | BD-R QL | 4x |
| BD-R (LTH) | 6x | BD-RE | 2x |
| BD-RE DL | 2x | BD-RE TL | 2x |
| M-DISC(BD) SL | 4x | M-DISC(BD) DL | 6x |
| M-DISC(BD) TL | 4x | ||
| MAXIMUM WRITE SPEED (DVD) | |||
|---|---|---|---|
| DVD-R | 8x | DVD-R DL | 6x |
| DVD-RW | 6x | DVD+R | 8x |
| DVD+R DL | 6x | DVD+RW | 8x |
| DVD-RAM | 5x | M-DISC(DVD) | 4x |
| MAXIMUM WRITE SPEED (CD) | |||
|---|---|---|---|
| CD-R | 24x | CD-RW | 24x |
| MAXIMUM READ SPEED (BD) | |||
|---|---|---|---|
| BD-ROM DL (Ultra HD Blu-ray) | 4x | BD-ROM TL (Ultra HD Blu-ray) | 4x |
| BD-ROM SL | 6x | BD-ROM DL | 6x |
| BD-R | 6x | BD-R DL | 6x |
| BD-R TL/QL | 4x | BD-R (LTH) | 6x |
| BD-RE | 6x | BD-RE DL | 6x |
| BD-RE TL | 4x | M-DISC(BD) SL | 6x |
| M-DISC(BD) DL | 6x | M-DISC(BD) TL | 4x |
| MAXIMUM READ SPEED (DVD) | |||
|---|---|---|---|
| DVD-ROM | 8x | DVD-ROM DL | 8x |
| DVD-R | 8x | DVD-R DL | 8x |
| DVD-RW | 8x | DVD+R | 8x |
| DVD+R DL | 8x | DVD+RW | 8x |
| DVD-RAM | 5x | M-DISC(DVD) | 8x |
| MAXIMUM READ SPEED (CD) | |||
|---|---|---|---|
| CD-ROM | 24x | CD-R | 24x |
| CD-RW | 24x | ||
| WRITE SUPPORT | |
|---|---|
| BD | BD-R (Single/Dual/Triple/Quadruple layer), BD-RE (Single/Dual/Triple layer), M-DISC (Single/Dual/Triple layer) |
| DVD | DVD-R, DVD-R DL, DVD-RW, DVD+R, DVD+R DL, DVD+RW, High speed DVD+RW, DVD-RAM, M-DISC(DVD) |
| CD | CD-R, CD-RW, HS CD-RW, US CD-RW, US+CD-RW |
| READ SUPPORT | |
|---|---|
| BD | Ultra HD Blu-ray (BD-ROM Dual/Triple layer), BD-ROM (Single/Dual layer), BD-R (Single/Dual/Triple/Quadruple layer), BD-RE (Single/Dual/Triple layer), M-DISC (Single/Dual/Triple layer) |
| DVD | DVD-ROM (Single/Dual layer), DVD-Video, DVD-R, DVD-R DL, DVD-RW, DVD+R, DVD+R DL, DVD+RW, DVD-RAM, M-DISC(DVD) |
| CD | CD-ROM (Mode 1&2), CD-ROM XA, Photo CD(Single/Multi-session), Video CD, CD-DA⁸, CD-Extra, CD-R, CD-RW |
| INTERFACE | |
|---|---|
| Interface | USB 3.1 Gen1(3.0)/2.0 |
| MINIMUM SYSTEM REQUIREMENTS - 4K ULTRA HD BLU-RAY | |
|---|---|
| Operating System | Windows10™ |
| CPU | 7th generation Intel® Core™ i7/i5 processor for Desktop PC (Kaby Lake-S), 7th generation Intel® Core™ i7/i5 processor for Notebook PC (Kaby Lake-H) *U processor is incompatible |
| GPU | Intel® HD Graphics 630 (Internal GPU for 7th generation processor) |
| Memory | 6GB minimum |
| External Display | HDMI 2.0a and HDCP 2.2 compatible, 4K display (3840 x 2160 minimum display resolution), HDR compatible(Incompatible display reproduces HDR contents with HDR>SDR format.) |
| Motherboard | Intel® SGX(Software Guard Extensions) support Intel® 200 series motherboard, HDCP 2.2/HDMI 2.0a output compatible, Intel® internal GPU output compatible |
| MINIMUM SYSTEM REQUIREMENTS - WRITE/READ BD/DVD/CD | |
|---|---|
| Operating System | Windows7™, Windows8™, Windows8.1™, Windows10™, Windows11™, Mac OS X 10.6-10.11, macOS Sierra 10.12, macOS High Sierra 10.13, macOS Mojave 10.14, macOS Catalina 10.15, macOS Big Sur 11.0, macOS Monterey 12.0, macOS Ventura 13, macOS Sonoma 14 , macOS Sequoia 15 |
| Hardware | 1 Available USB 3.1 Gen1(3.0)/2.0 port |
| Processor | Intel® Core™ 2 Duo E6750 (2.66MHz), AMD® Phenom 9450 (2.1GHz) or faster |
| Video | Intel G45, NVIDIA® GeForce® 8600GT, AMD Radeon® HD2600 or faster |
| Display | HDCP compliant display required for Blu-ray playback, 1024 x 768 minimum display resolution |
| Memory | 2GB RAM required for Blu-ray playback, 3GB RAM or greater recommended for editing HD video |
| Hard Disk Space | 5GB available space minimum, 128GB or more available space required for creating quad-layer Blu-ray Discs |
| OTHER SPECIFICATIONS | |
|---|---|
| Data Buffer | 4 MB |
| Mounting Orientation | Horizontal, Vertical with Vertical stand |
| DIMENSIONS | |
|---|---|
| Dimensions (mm) | 135 mm x 135 mm x 18.0mm (W x D x H) |
| Weight | 280 g |
CYBERLINK SOFTWARE INCLUDED
Application Software for Mac is not included.
-
-
PowerDVD14 UHD-BD
PowerDVD is the market-leading media player for Blu-ray & Ultra HD Blu-ray. Watch high definition movies. Enjoy better picture and audio quality than streaming.
-
-
Power2Go8®
Burn all media to any disc, includes system recovery tools. BDXL™ format supports 128GB Quadruple Layer and 100GB Triple Layer Blu-ray discs.
-
-
PowerDirector15 LE
Make movies with fast, powerful video editing tools. Edit your high definition movies and upload them to social media websites with the included software.
-
-
Instant Burn5
Burn content to disc instantly with packet writing technology.
-
-
Label Print2.5
Design and print stylish disc labels in just 4 easy steps.
-
-
PhotoDirector8 LE
Complete editing and adjustment tools to bring your photos to life.
-
-
ColorDirector5 LE
ColorDirector is a way for video color editors of all skill levels to dramatically improve their projects.
-
-
AudioDirector7 LE
AudioDirector contains cutting-edge tools that make editing and fixing audio tracks fast and simple when editing audio for video projects.
To playback 4K Ultra HD Blu-ray, HDMI2.0a, HDCP2.2 and HDR (recommended) compatible are required separately. For checking your UHD playback environment, please use the “CyberLink UHD BD Advisor Tool” on our web site. https://pioneer.jp/support/download/index-e.html
Supported media list can be found at Pioneer official website.
When using a USB 2.0 port, BD writing/reading speed doesn’t achieve 6x.
https://pioneer.jp/device_e/product-e/ibs/device_e/dev00003r_e.html
1 Triple and quadruple layer BDXL discs can only be used in BDXL drives.
2 16x BD-R write speed achieved using certain media. Refer to the “Supported media list”.
3 PowerRead is not guaranteed to work with all disc conditions or under all PC environments.
4 PureRead4+ is not guaranteed to work with all disc conditions or under all PC environments.
5 HDCP (High-bandwidth Digital Content Protection) display device is required only for playback of high-definition copy protected content (for example, a Hollywood Blu-ray title). For such content, the connection between the PC and the display device must be made using a digital DVI, HDMI, or DisplayPort cable.
6 Support for writing DVD-R Version 2.0 For General. Unable to write DVD-R for Authoring 3.95GB and 4.7GB
7 Compatible with DVD-RAM Version 2.0/2.1/2.2 without cartridge. Unable to write RAM2 format disc.
8 New Maxi Disc cannot be read.
Note: Auto Quiet mode, PureRead4+ and Peak Power Reducer can be configured as well as enabled and disabled with the Pioneer BDR-XS07TUHD Drive Utility. The utility will be provided on the Pioneer Web site http://pioneer.jp/device_e/product-e/ibs/device_e/dev00001r_e.html
